Firmstone (Tianjin) International Limited is one of the leading manufacturers and suppliers of raw material pvc wire in China. We are committed to providing high quality customized products for global clients. If you're going to buy durable raw material pvc wire made in China, welcome to get pricelist from our factory.
Premium virgin PVC resin coated galvanized wire. Smooth, uniform surface, free from impurities, cracks, and coating marks. Stable insulation, excellent anti-aging, consistent color across batches. Inner zinc and outer PVC coating thickness fully customizable per technical requirements and usage scenarios.
Product Specification
|
Core Wire Material |
Core Wire Diameter (mm) |
Outer Diameter (mm) |
Tensile Strength Min (MPa) |
Tensile Strength Max (MPa) |
Elongation Min (%) |
Standard Coil Weight (kg) |
Available Colors |
Typical Applications |
|
Hot-dip Galvanized/ |
0.32 |
0.50 |
350 |
550 |
>10 |
1-5 |
Green, Black, White, etc., |
Crafts, fine binding, floral wire |
|
0.50 |
0.80 |
350 |
550 |
>10 |
1-5 |
Green, Black, White, etc., |
Crafts, fine binding, floral wire |
|
|
0.75 |
1.20 |
340 |
540 |
>10 |
1-5 |
Green, Black, White, Blue,etc., |
Binding wire, cable ties, gardening |
|
|
0.90 |
1.40 |
340 |
530 |
>10 |
1-500 |
Green, Black, White,etc., |
General binding, wire mesh coating |
|
|
1.00 |
1.60 |
330 |
520 |
>10 |
1-500 |
Green, Black, White, Yellow,etc., |
Fencing mesh, agricultural use |
|
|
1.20 |
2.00 |
320 |
510 |
>10 |
1-100 |
Green, Black, White, Blue,etc., |
Chain link fence, gabion mesh |
|
|
1.50 |
2.40 |
320 |
500 |
>10 |
1-800 |
Green, Black, White,etc., |
Vineyard trellis, heavy binding |
|
|
1.60 |
2.60 |
310 |
500 |
>10 |
1-800 |
Green, Black, White, Yellow,etc., |
Cable armoring, construction |
|
|
1.80 |
3.00 |
310 |
500 |
>10 |
1-800 |
Green, Black, White,etc., |
Heavy duty fencing, farm fence |
|
|
2.00 |
3.20 |
300 |
500 |
>10 |
1-800 |
Green, Black, White, Blue,etc., |
Barbed wire, security fencing |
|
|
2.50 |
3.80 |
300 |
500 |
>10 |
1-800 |
Green, Black, White,etc., |
Gabion boxes, heavy industrial |
|
|
3.00 |
4.00 |
290 |
500 |
>10 |
1-800 |
Green, Black, White,etc., |
Stone cage netting, structural use |
|
|
4.00 |
5.00 |
290 |
500 |
>10 |
1-800 |
Green, Black, White,etc., |
Gabion boxes, heavy industrial |
Material
The product adopts a dual-layer structural design with strict material selection standards. The inner metal wire supports three mainstream specifications: ordinary black wire, electro-galvanized wire and hot-dipped galvanized wire, each with stable structural toughness and anti-rust foundation. The outer protective coating is made of 100% brand-new virgin PVC plastic pellets, with no recycled scraps, inferior fillers or impure additives added, ensuring the overall durability, corrosion resistance and environmental safety of the wire.
Product Application
As a versatile basic metal plastic material, it is widely used as raw material for producing PVC mesh, and also serves as professional binding wire, protective fencing wire, handmade craft wire, horticultural plant tying wire, and auxiliary binding accessories for construction engineering.
Production Process
The standardized production process ensures stable product quality: first, complete galvanized wire straightening and professional surface cleaning to remove dust and oxide layers; then mix and melt high-purity virgin PVC pellets at constant temperature; evenly extrude the molten PVC material onto the wire core for integrated coating; conduct circulating water cooling and natural air drying for shaping; finally finish strict quality inspection, standardized coiling and sealed packaging.
Precaution for Use
Although made of high-purity virgin PVC material with good durability, the wire should avoid excessive overstretching beyond its tensile range to prevent structural deformation and coating damage. During manual installation and cutting, avoid sharp tool scratching to protect the intact PVC coating and maintain insulation and anti-rust performance. For long-term outdoor deployment, regular routine checks are recommended to remove surface dust and avoid prolonged accumulation of corrosive substances. Unused wire rolls should be stored in dry, ventilated and shady environments to prevent long-term direct sunlight exposure and damp erosion that may cause coating aging and discoloration.
Compare with Other Products
Compared with recycled material PVC wire, this virgin raw material PVC wire features purer coating material, smoother surface, uniform color, better insulation and anti-aging performance, with no impurity defects, making it suitable for medium and long-term formal usage scenarios instead of only temporary applications. In contrast to high tensile strength PVC wire and high carbon steel PE coated wire, it has moderate tensile strength and conventional corrosion resistance, with more affordable pricing and higher finished product qualification rate. It serves as the standard-grade basic coated wire, offering stable quality and wide compatibility, and is the most versatile option for general mesh production, daily binding and conventional fencing projects.
