Firmstone (Tianjin) International Limited is one of the leading manufacturers and suppliers of concertina razor wire in China. We are committed to providing high quality customized products for global clients. If you're going to buy durable concertina razor wire made in China, welcome to get pricelist from our factory.
Concertina Razor Wire – top-tier military and defense-grade security barrier for ultra-high anti-intrusion protection. Precision-stamped galvanized steel razor blades with reinforced high-tensile core wire, automatically coiled into continuous spiral loops with stable tension. Densely packed sharp blades and reinforced structure deliver anti-climb, anti-cut, anti-tear and anti-break performance, extremely difficult to cross or destroy with conventional tools. Optional ZnAl alloy coating for long-term outdoor durability, effective year-round for high-security defense applications.
Product Specification
|
Model |
Blade Thickness (mm) |
Core Wire Diameter (mm) |
Barb Spacing (mm) |
Blades per Meter |
Coil Diameter (mm) |
Standard Length per Roll (m) |
|
BTO-10/12/16/18/22/28/30 |
0.50 |
2.5 |
26 |
380 |
450 |
10-50 |
|
0.50 |
2.5 |
26 |
380 |
500 |
||
|
0.50 |
2.5 |
33 |
300 |
600 |
||
|
0.60 |
3.0 |
34 |
290 |
700 |
||
|
0.50 |
2.5 |
45 |
220 |
800 |
||
|
0.60 |
3.0 |
45 |
220 |
900 |
|
Model |
Blade Length (mm) |
Blade Width (mm) |
Blade Thickness (mm) |
Core Wire Diameter (mm) |
Barb Spacing (mm) |
Coil Diameter (mm) |
Blades per Loop |
Standard Length per Roll (m) |
|
CBT-60 |
21.0 |
15.0 |
0.50 |
2.5 |
26 |
600 |
63 |
10-50 |
|
CBT-65 |
21.0 |
15.0 |
0.60 |
2.5 |
26 |
650 |
70 |
Material
Concertina razor wire adopts dual high-strength galvanized structural materials for comprehensive performance assurance. The outer razor blade strip is made of high-quality hot-dip galvanized steel strip, featuring uniform thickness, high hardness and excellent stamping forming performance, which ensures sharp blade toughness without easy cracking or passivation. The inner supporting core wire adopts high tensile galvanized steel wire, providing stable penetrating support and overall structural tension to prevent spiral coil deformation and scattering. In addition to conventional hot-dip galvanized materials, high-performance ZnAl alloy coating is available as an upgraded option. The alloy layer features denser texture and stronger weather resistance, effectively resisting salt fog, ultraviolet radiation and chemical corrosion, greatly improving the overall service life of the razor wire in extreme outdoor environments.
Product Application
With ultra-high anti-destruction and anti-intrusion capabilities, concertina razor wire is exclusively applied in various high-standard key security restricted areas. It is widely used for national border defense isolation, military zone perimeter closed protection, prison and detention center high-level security isolation, customs station safety boundary division, power substation key facility protection, chemical factory hazardous restricted area enclosure, and airport isolation wall safety reinforcement, serving as the core defense material for high-risk and high-security level protection projects.
Production Process
The product adopts precise automated standardized production process to ensure defense-grade quality: firstly, complete professional steel strip slitting and equidistant stamping to form neat and sharp razor blades; secondly, penetrate high-tensile galvanized steel wire as the inner supporting core to enhance overall structural stability; thirdly, adopt automatic rolling equipment to shape continuous standard spiral concertina coils; fourthly, implement spot welding fixing for cross joints to prevent coil loosening and separation; finally, conduct comprehensive surface anti-corrosion inspection, followed by standardized bundling and pallet packaging for long-distance transportation and large-scale engineering laying.
